MODEL
|
WMS-48200A1
|
|
Capacity Energy
|
10.75kwh
|
|
Capacity Ah
|
200Ah
|
|
Suggested SOC
|
10%-90%
|
|
Usable Capacity
|
10.75kwh
|
|
Nominal Voltage
|
48V
|
|
Operating Voltage
|
41V-55V
|
|
Maximum Charging/
Discharging Current
|
100A/100A Per Pack
|
|
BMS
|
Robust Muliti Point Monitoring BMS Pre Installed
|
|
Scalablle
|
Yes.Maximum 16Pack
|
|
Life Cycle(0.5C 25C)
|
6000 Cycles@0.5C，85% DOD，70% EOL35℃
|
|
Rated Capacity
|
105 Ah @ 0.5C
|
|
Warranty BAT
|
10 Years,whichever comes sooner
|
|
Operation Temperature
|
Charge：0~55℃，Discharge：-20~60℃
|
|
Storage Temperature
|
Short-term(Within 1 month)：-20~45℃
Long-term(Within 1year)：0~35℃
|
|
Weight
|
90KG
|
|
Dimensions
|
770X500X160mm
|
|
Certifications
|
MSDS,UN38.3,ROHS,IEC62619,UL
|
|
IP Grade
|
IP54
|
|
Communication
|
RS232 RS485 CAN
|
