MODEL
|
SR4830
|
|
PV INPUT PV
|
|
Maximum PV Voltage VOC
|
135V -20°C 145V 25°C
|
|
System Voltage
|
12V/24V/48V auto 36V set
|
|
MPPT Voltage Range
|
Battery voltage+3V-120V
|
|
Suggest Input VOC Voltage
|
22V/40V/60V/80V
|
|
Number of MPPT Trackers
|
1
|
|
MAX.PV INPUT POWER
|
|
12V
|
400w
|
|
24V
|
800W
|
|
36V
|
1200W
|
|
48V
|
1600W
|
|
CHARGER OUTPUT DC
|
|
Max. Output Current(revisable)
|
30A
|
|
Rated Load Current
|
20A
|
|
Max. Capacitive Load Capacity
|
100UF
|
|
Ripple Voltage
|
<0.5%
|
|
Applicable Battery Type
(ex-factory default lead-acid battery)
|
Sealed lead-acid battery/Gel battery/Flooded battery/Tithium battery,
other battery types can be customized
|
|
EFFICIENCY
|
|
Max. Efficiency
|
<98%
|
|
MPPT Efficiency
|
>99%
|
|
PROTECTION
|
|
Protect function
|
PV input over voltage protection?PV input over current protection
output over voltage protection?output over voltage protection
PV/battery anti-reverse protection?over temperature protection
Battery low/high voltage protection?load over current protection
Load short circuit
|
|
REGULAR DATA
|
|
Unloaded Loss
|
<1.5w
|
|
Operating Temperature
|
-20°C~+45°C
|
|
Dimension. D*W*H?mm?
|
279*201*96mm
|
|
Net Weight ?kgs?
|
3.6kg
|
|
Elevation Height
|
0% to 95% No condenser
|
|
Cooling Concept
|
Natural
|
|
IP Rate
|
IP 20
|
|
Communication Interface
|
RS232 Extensible interface
|
